MR CARTOOL T105 Smoke Machine for cars is a universal and professional automobile pipe leakage smoke tester. It allows you to determine the leak points more quickly within a few minutes. By observing the pressure indicator, the leakage is clear at a glance. Moreover, our smoke tester is detachable, small in size, easy to store, time-saving and labor-saving. It is widely used in various auto repair shops and DIYer technicians.
How to do a leakage test?
1. Fill 20ml of baby oil into the detector for the first time. Open the engine cover, and hang the detector in the cover.
2. Disconnect the pipe that needs to be connected with the detector.
3. Connect detector with DC12V battery, turn on the power switch, and the detector starts to work.
4. In about 30 seconds, the pipe will be filled with smoke. Check the leak points. Please use head lamp if necessary.
The Main Functions：
Tightness Test: It can test the tightness and leakage of the tested pipeline under system pressure.
Intake System Test: it can test the air tightness and damage degree of the pipes in the intake system.
Exhaust System Test: it can test the air tightness and damage degree of the pipes in the exhaust system.
EVAP System Test: it can test the leakage of fuel evaporation in the EVAP system.
MR CARTOOL T105 Smoke Machine For Cars Features :
1. [Wide range of applications] For detecting the leakage of pipe systems on cars, motorcycles, snowmobiles, off-road vehicles, ATVs, light trucks and speedboats boats. Works on all vehicle makes and models.
2. [Powerful and easy to operate] The MR CARTOOL T105 for cars has its own air pump, it does not rely on other air machine,Connect the detector with DC12V battery, It can be outputs lots of Smoke within 30 seconds after turning on.
3. [Advanced technology] It works on the EVAP system (we also have another version that is specially designed for the EVAP system, one of the best EVAP smoke machines).
4. [Overheat & Anti-frost protection] The detector has smart protector. If it exceeds the working limit, for e.g over 80℃. It will power off automatically.
5. [2 years warranty] For damage caused by non-human factors, we promise to resend parts for free within 2 years.
Main Unit Structure :
Hook: To hang the detector when detecting:
Working Indicator: It is lit when the detector works
Power Switch: Power it on, and the detector works
Smoke Output Tube: The smoke outlet which connects with the detection port
Power Clamp: To connect with vehicle battery. The voltage is DC12V
Product Parameter of T105 Smoke Machine for Cars：
Power supply: 12V
Air source: built-in
Test oil capacity：10ML
Dimensions of the Main Unit160x280x190mm
Function Comparison with other models:
1. When you use this MR CARTOOL T105 smoke machine for the first time, fill with 20ml oil. Please be careful NOT to beyond this range.
2. The testing liquid: both liquid paraffin and baby oil are OK.
3. Fresh oil can be filled with only when the smoke gets thin, and it can’t be filled over 20ml each time.
4. Before filling fresh oil, please pour out the left oil in the detector & replace the detector oil regularly.
5. During the process of leak detection, please keep away from smoke-sensitive parts.
6. Do NOT run the detector for over 8 minutes continuously. It needs interval rest.
7. The detector has an intelligent protector, if it exceeds the working limit, such as over 80 ℃, it will automatically turn off the power. In this case, please operate it later.
8. The round part of this detector has temperature, please be careful to avoid burns.
9.If the test pipe needs to be disconnected in the middle, please secure the other side with a rubber stopple.
Packing List :
1pc* MRCARTOOL T105 smoke machine for cars main unit
1pc* Power cord clamp
1pc* Smoke hose
1pc set* Hard rubber hose plug
1pc* Test oil bottle
1pc* Valve core wrench
1pc* EVAP specilal connector & rubber connector part
1pc* Standard cone adapter
1pc* Universal airbag adapter
1pc* User manual
WHY CHOOSE OUR T105 SMOKE MACHINE FOR CARS?
1. More directly, accurate and faster than traditional leak detection methods such as soap bubbles and throttle cleaners.
2. Adopting smoke generator technology facilitate smoke stability and large amount output.
3. Built-in air pump, ready for testing and maintenance.
4. Compact, lightweight design allows for any placement of machine for work.
5. Test oil is non-toxic and non-corrosive.
6. The air pump can be regulated separately.
7. The smoke generator can be regulated separately.
