If you work in an automotive repair shop in the U.S. or Europe, you’ve seen those “Check Engine” lights tied to EVAP codes more times than you can count. EVAP leaks are sneaky — tiny hose cracks, loose caps, bad valves — and they won’t fix themselves.
That’s where a automotive evap smoke machine like the MRCARTOOL T105 comes in. Whether you call it an automotive smoke leak detector, a smoke machine automotive techs love, an auto smoke tester, or simply a vacuum leak smoke machine, the idea is the same: introduce a harmless visible smoke into the EVAP system so leaks show up fast. No guessing parts or repeat visits.
Here’s how to do it right.
Why Smoke Test EVAP Systems?
Modern cars are sealed systems. The EVAP (Evaporative Emission Control) system traps fuel vapors and routes them to the engine to burn. When there’s a leak, your customer’s car fails emissions and throws codes like P0442, P0455, P0456 — all signs of leaks.
With a smoke machine automotive techs can pinpoint leaks in minutes instead of hours.
Tools You Need
-
MRCARTOOL T105 automotive evap smoke machine (your smoke source)
-
Appropriate adapters for EVAP ports
-
Basic hand tools (screwdrivers, pliers)
-
Safety glasses and gloves
$89.90 Original price was: $89.90.$69.90Current price is: $69.90.
$149.00 Original price was: $149.00.$85.90Current price is: $85.90.
$319.90 Original price was: $319.90.$259.00Current price is: $259.00.
$21.00 Original price was: $21.00.$13.99Current price is: $13.99.
Step-by-Step: How To Smoke Test For EVAP Leaks
1. Prep the Vehicle
Park the car on level ground, engine off, parking brake set. If the engine is hot, let it cool. You’re not performing surgery — no need to burn yourself.
Remove the EVAP system’s service port cap if present. In many cars, there’s a Schrader valve on the EVAP canister line. That’s your access.
2. Set Up the Automotive Smoke Leak Detector
Take your auto smoke tester (again, the MRCARTOOL T105) and fill it with the recommended fluid. Connect the hose and pick the correct adapter for the OEM EVAP port.
Check that all seals on the machine are snug. No leaks on your tester or you’ll chase your own smoke.
3. Connect to the EVAP System
Attach the smoke hose to the service port. The fit should be snug — like a good handshake, not a limp wrist.
4. Pressurize and Introduce Smoke
Turn on the smoke generator. You’re using this vacuum leak smoke machine in reverse: you’re not pulling vacuum, you’re gently introducing smoke into the EVAP system.
If the system has a TP (test port), hook to that. If not, use the canister purge line after removing the valve.
Let the machine build a little pressure — just enough to push smoke through the hoses and canister area.
5. Watch for Escaping Smoke
Now the fun part: watch, sniff (seriously, your nose works), and listen.
Common leak points:
-
Loose or missing gas cap
-
Cracked vacuum hoses
-
Faulty purge valve
-
Failed vent valve
-
Charcoal canister cracks
Smoke will reveal itself at the leak — like a tiny ghost in the machine.
6. Fix the Leak
Once you see where the smoke is escaping, replace the faulty part. Sometimes it’s a hose, sometimes it’s a valve. The key is confidence — you’re not guessing.
7. Verify the Repair
After repair, run the smoke test again. No smoke out means no leak. That’s a good thing.
Common Questions Shop Owners Ask
Q: Can I use this in a running engine?
No. Smoke tests for EVAP leaks are done with the engine off. Introducing smoke while the engine is running will simply get smoke sucked into the intake and confuse you — not your customer.
Q: How much pressure should I use?
Very low pressure. You’re not inflating a tire. Think “gentle push.” Too much pressure can damage sensors or diaphragms in the system.
Q: What makes the MRCARTOOL T105 better than other smoke machines?
As an automotive smoke leak detector, the T105 hits the sweet spot of output, reliability and ease of use. It’s robust enough for daily shop use, yet simple enough that a new tech gets confident fast.
Q: My code returns after smoke test — what now?
If the smoke test shows no visible leaks but codes persist, check:
Q: Do I need special adapters?
Yes. Different manufacturers use different service ports or hose sizes. Make sure your auto smoke tester kit has a set of adapters and fittings. A kit without adapters is like a wrench without the right size.
Final Thoughts
Performing a smoke test with a quality vacuum leak smoke machine isn’t a luxury — it’s a necessity in today’s repair environment. It saves time, parts, and headaches. With the procedure above, you’ll spot leaks others miss and get those EVAP codes cleared fast.
If you want to talk about demo units, pricing, or which adapters fit which cars — just ask. Let’s help you make smoke testing a standard in your shop.
